单元组成Component:LF 1x10＂单元/HF 2x1.4＂单元
频率响应Frequency Response(-10dB):65Hz-18kHz
灵敏度Sensitivity(SPL1W/1M):97dB
标称阻抗Nominal Impedance:8Ω
额定功率(AES):500W
指向性Dispersion(H×V):110°×9°
最大声压级MAX SPL@1m:131dB
连接插座Connector:Speakon NL4
尺寸Dimensionns(W×H×D):480mm×300mm×360mm
重量Weight:15kg
单元组成Component:LF 2x18＂单元
频率响应Frequency Response(-10dB):28Hz-90Hz
灵敏度Sensitivity(SPL1W/1M):102dB
标称阻抗Nominal Impedance:4Ω
额定功率(AES):3000W
最大声压级MAX SPL@1m:141dB
连接插座Connector:Speakon NL4
尺寸Dimensionns(W×H×D):1190mm×536mm×670mm
重量Weight:85kg
