单元组成Component:LF 2x12＂N单元/HF 4x1.4＂N单元
频率响应Frequency Response(-10dB):60Hz-20kHz
灵敏度Sensitivity(SPL1W/1M):112dB
标称阻抗Nominal Impedance:4Ω
额定功率(AES):Coacil 1200W
最大声压级MAX SPL@1m:146dB
连接插座Connector:Speakon NL4
尺寸Dimensionns(W×H×D):480x675x560mm
重量Weight:45kg
单元组成Component:LF 2x18＂单元
频率响应Frequency Response(-10dB):28Hz-90Hz
灵敏度Sensitivity(SPL1W/1M):102dB
标称阻抗Nominal Impedance:4Ω
额定功率(AES):3000W
最大声压级MAX SPL@1m:141dB
连接插座Connector:Speakon NL4
尺寸Dimensionns(W×H×D):1190mm×536mm×670mm
重量Weight:85kg
